Neuron Humidity IP67

Features

Long life battery – up to 10 years lifetime

Continuous measurement and instant alarm

Adjustment of parameters such as measurement frequency on request

Define your own alarm levels in the Neuron app

Receive alerts as push notifications, emails or SMS

Easily connect the sensor to the system with the QR-code on the sensor. Ensures immediate and accurate registration in the app on your phone/PC/tablet

The sensor transmits data to your nearby Neuron Gateway which then again communicates with the Neuron Cloud

Neuron system benefits

Robust sensors
Suitable for rough environments
Wireless
Wireless sensor with integrated battery
Long lifetime
Typical 10 years battery life
Quick installation
Wireless, installed and operational in minutes
Collect and deliver data
Data delivery through API and app
Broad offering
More than 50 different sensor types available

Operational specification

Measuring Range:
0-95% RH -20°C – 70°C

Resolution:
0.1% RH and 0.1°C

Accuracy:
± 2% RH (20-80% RH)
± 3.5% RH (0-20% RH and 80-100% RH)

Accuracy Temp.:
± 0.5°C (see graph)

Long Term Drift:
Hum.: <0.5% RH/year Temp.: <0.05°C/year
(Normal conditions)

Measuring Frequency*:
Every 2 min.

Report frequency*:
Reports every 2 min.

Trigger for Critical Data Transmission*:
5% pp RH change in measurement

Operating Environment:
Ambient temperature: -20 – 70 ºC
Relative humidity: 0-95% (non-condensing)
Altitude: < 2000m above sea level
Pollution degree: 3

IP Grade:
IP 67, indoor use.

Radio Frequency:
863-870 MHz / 902-928 MHz

Battery Type
Lithium Manganese Dioxide, 3.0V

Expected Operating Time**:
Up to 10 years

* Adjustable on request
** Depends on measurement frequency, amount of critical data transmissions and ambient temperature

Physical specification

Materials:
Radio Transmitter: Polyurethane /
Neodymium magnet
Humidity probe: Plastic

Dimensions LxWxH:
Radio Transmitter: 71x52x15 mm
Humidity probe: 46×12.5 mm
Cable: 1.8 m

Regulatory

Certifications:
CE marking
UK CA
FCC
Industry Canada

Directives/Standard:
IEC 61010-1:2010
FCC Part 15C
RED 2014/53/EU Radio
Equipment Regulations 2017

Installation

Productsheet_GaugePressure_Page_3_Image_0001

Productsheet_GaugePressure_Page_3_Image_0002

Productsheet_GaugePressure_Page_3_Image_0003

Productsheet_GaugePressure_Page_3_Image_0004

Neuron sensors are ready for use out of the box and will start logging data after registering the sensor in the app. Even though Neuron sensors deliver great range and long battery life, following some simple guidelines for mounting of the sensor and gateway can greatly improve signal coverage and lifetime of the sensor.

To ensure optimal antenna performance and signal strength, the sensor should be placed elevated with some distance to fixed objects. Keep in mind that RF-signals are greatly affected by close metallic surfaces.

For sensors with an external antenna, the antenna should be clear off the metallic surface.

For sensors operating in environments with greatly varying temperatures, care should be taken to avoid putting the sensor in unnecessary stress. Very high or low temperatures will affect the battery life and the signal strength of the sensor. While some sensors must be close to the source of heat or cold, other sensors have external probes which allow the sensor to be placed at a distance.

Fastening
The small, compact blue Neuron sensors are fitted with fastening holes for use with cable ties. The sensors are also delivered with double-sided tape that may be used for fastening of the sensors.

All the black Neuron sensors, like the Neuron IR380 and Neuron Vibration, are fitted with a strong magnet at the back for easy fastening. If there is no magnetic surface, then double-sided tape is a good solution.
